Model: IRHD160-330IL40
Specifications Chart:
Model |
Capacity m3/min PDP |
Air In/Out Connection BPST (in) |
Max Op Pressure bar (g) |
Dimensions | Weight |
Std Power Supply V/Ph/Hz |
|||
| m3/hr | m3/min | Length(mm) | Width (mm) | Height (mm) | |||||
| D160IL | 160.00 | 2.67 | 1 | 5-10 | 1040 | 770 | 1580 | 240 | 230/1/50 |
| D200IL | 200.00 | 3.33 | 1 | 5-10 | 1040 | 770 | 1580 | 255 | 230/1/50 |
| D275IL | 275.00 | 4.58 | 1 1/2 | 5-10 | 1140 | 810 | 1680 | 320 | 230/1/50 |
| D350IL | 350.00 | 5.83 | 1 1/2 | 5-10 | 1140 | 810 | 1680 | 332 | 230/1/50 |
| D500IL | 500.00 | 8.33 | 2 | 5-10 | 1240 | 815 | 1700 | 420 | 230/1/50 |
| D700IL | 700.00 | 11.67 | 2 | 5-10 | 1340 | 925 | 1730 | 506 | 230/1/50 |
| D900IL | 900.00 | 15.00 | 2 | 5-10 | 1440 | 1100 | 2100 | 709 | 230/1/50 |
| D1000IL | 1000.00 | 16.67 | 2 | 5-10 | 1440 | 1100 | 2100 | 755 | 230/1/50 |
| D1600IL | 1600.00 | 26.67 | 3 | 5-10 | 1630 | 1310 | 2230 | 1015 | 230/1/50 |
| D2000IL | 2000.00 | 33.33 | 3 | 5-10 | 1630 | 1310 | 2230 | 1100 | 230/1/50 |
| D2500IL | 2500.00 | 41.67 | DN 10 | 5-10 | 1980 | 1400 | 2040 | 1350 | 230/1/50 |
| D3300IL | 3300.00 | 55.00 | DN 125 | 5-10 | 2140 | 1550 | 2340 | 1772 | 230/1/50 |
Performance based on:
- Ambient Pressure equal to 1 bar g
- Ambient temperature equal to 25 °C
- Dyer inlet air relative humidity 100%
- Dyer inlet pressure equal to 7 bar g
- Dyer inlet temperature equal to 35 °C
Operating limitations:
- Ambient: Min 1 °C, Max 50 °C
- Air inlet temperature Max 50 °C
- Compliance with PED 97/23/EC and CE (Non ASME)
