Herman Industries Houmann HI712 Metal Cutting Band Saw


HI712G-912B

Model: HI712G-912B

Features:

  • The saw bow with locking handle can be rotated from 0° to 45° the band saw can be used both vertically and horizontally.
  • The falling speed of saw bow is controlled by hydraulic cylinder, can be move freely.
  • Equipped with a sizing device (the machine will automatically stop after sawing the materials).
  • The band saw has a power break protection device (the machine will automatically power off when the rear protective cover is opened).
  • The cooling system can prolong the service life of saw blade and improve the precision of workpiece.
  • Equipped with a block feeder (with fixed sawing length)

Click to share:
Unit/Model  HI-712G HI-912G HI-912B
Capacity    Circular at 90° (mm) 178  299  299
Rectangular at 90° (mm) 178x305  178x305 178x305
Circular at 45° (mm) 127  150  150
Rectagular at 45° (mm) 120x115  127x150  127x150
Blade Speed   60Hz (mpm) 34, 70, 104  37, 78, 115  32, 60, 88, 115
50Hz (mpm) 29, 59, 87  31, 65, 95  26, 50, 73, 95
Motor Power 750W 1HP (3PH), 1.1 kW/1.5HP (1PH) 750W 1 HP (3PH)/1.5 kW 2HP (1PH)  750W 1 HP (3PH)/1.5 kW 2HP (1PH)
Drive   Gear  Gear  V-Belt
Packing Size  (cm) 129x54x115  158x62x115  154x59x115
N.W/G.W  (kg) 170/194  220/250  230/260
