Fitur/Keterangan:
|
|
CCN |
Power KW |
Capacity
|
Operating bar(g)
|
Pressure psi(g)
|
Motor
|
Dimension |
Weight Kg |
Air Tank Litre |
|
|
Model |
m3/min |
ft3/min |
L×W×H |
|||||||
|
231XB3/35 |
15835812 |
2.2 |
0.14 |
4.8 |
35.2 |
500 |
380-415V/3ph/50hz |
908L×540W×590H |
165kg |
W/O |
|
7T4XB5/70 |
15835838 |
4.1 |
0.18 |
6.2 |
70.4 |
1000 |
380-415V/3ph/50hz |
1260L×950W×800H |
276kg |
W/O |
|
7T2XB10/35 |
15835820 |
7.5 |
0.62 |
21.6 |
35.2 |
500 |
380-415V/3ph/50hz |
1270L×810W×830H |
420kg |
W/O |
|
15T2XB15/35 |
15835507 |
11.2 |
1.07 |
37.3 |
35.2 |
500 |
380-415V/3ph/50hz |
1400L×1030W×860H |
473kg |
W/O |
|
15T2XB15/55 |
15835515 |
11.2 |
0.92 |
32.9 |
56.3 |
800 |
380-415V/3ph/50hz |
1400L×1030W×860H |
473kg |
W/O |
|
15T2XB15/70 |
15835523 |
11.2 |
0.85 |
29.8 |
70.4 |
1000 |
380-415V/3ph/50hz |
1400L×1030W×860H |
473kg |
W/O |
|
PA-15/30 |
15835531 |
11.2 |
1.07 |
37.3 |
35.2 |
500 |
380-415V/3ph/50hz |
1400L×1030W×860H |
473kg |
W/O |
|
15T4XB15/245 |
15835762 |
11.2 |
0.54 |
19.2 |
246.5 |
3500 |
380-415V/3ph/50hz |
1425L×1030W×860H |
473kg |
W/O |
|
15T4XB20/245 |
15835788 |
14.9 |
0.63 |
21.9 |
246.5 |
3500 |
380-415V/3ph/50hz |
1425L×1035W×1150H |
540kg |
W/O |
|
H15T4XB15/344 |
15835770 |
11.2 |
0.52 |
18.1 |
352.1 |
5000 |
380-415V/3ph/50hz |
1425L×1035W×1150H |
520kg |
W/O |
|
H15T4XB20/344 |
15835796 |
14.9 |
0.62 |
21.4 |
352.1 |
5000 |
380-415V/3ph/50hz |
1425L×1035W×1150H |
540kg |
W/O |
|
15T2XB15/35-FF |
15830573 |
11.2 |
1.07 |
37.3 |
35.2 |
500 |
380-415V/3ph/50hz |
1400L×1030W×860H |
473kg |
W/O |
|
15T2XB15/55-FF |
15830565 |
11.2 |
0.92 |
32.9 |
56.3 |
800 |
380-415V/3ph/50hz |
1400L×1030W×860H |
473kg |
W/O |
|
15T2XB15/70-FF |
15830577 |
11.2 |
0.85 |
29.8 |
70.4 |
1000 |
380-415V/3ph/50hz |
1400L×1030W×860H |
473kg |
W/O |
|
PA-15/30-FF |
15831985 |
11.2 |
1.07 |
37.3 |
35.2 |
500 |
380-415V/3ph/50hz |
1400L×1030W×860H |
473kg |
W/O |
|
15T4XB15/245-FF |
15830680 |
11.2 |
0.54 |
19.2 |
246.5 |
3500 |
380-415V/3ph/50hz |
1425L×1030W×860H |
473kg |
W/O |
|
15T4XB20/245-FF |
15830748 |
14.9 |
0.63 |
21.9 |
246.5 |
3500 |
380-415V/3ph/50hz |
1425L×1035W×1150H |
540kg |
W/O |
|
H15T4XB15/344-FF |
15830755 |
11.2 |
0.52 |
18.1 |
352.1 |
5000 |
380-415V/3ph/50hz |
1425L×1035W×1150H |
520kg |
W/O |
|
H15T4XB20/344-FF |
15830797 |
14.9 |
0.62 |
21.4 |
352.1 |
5000 |
380-415V/3ph/50hz |
1425L×1035W×1150H |
540kg |
W/O |
|
H15T6XB20/420-FF |
15837206 |
14.9 |
0.54 |
18.9 |
422.5 |
6000 |
380-415V/3ph/50hz |
1410L×1035W×1200H |
650kg |
W/O |
Spesifikasi:
- Regulation: Standard - Auto Stop/Start
- Constant speed available at additional cost on 7T4, 15T2, H15T4 and H15T6 package
- Standard constant speed control on PA models
- Auto condensate drain trap standard on 15T4, H15T4 and H15T6
- Direct-on-line starter standard for 15hp and below
- Star-delta starter standard for 20hp
- Low oil level switch standard on 15T4, H15T4
- Pressure switch included (supplied loose)
- 100% cast icon frame and separately-cast cylinders
- Precison machined high quality cast iron cylinders with deep radial fins, suitable for heavy duty operation and longer life
- Heat treated stainles steel finger valve assemby, provides a large flow are resulting in lesser heat and carbon build-up. Easy removal & servicing
- Runs cooler, resulting in a more efficient compressor that consumes lesser power and lasts longer
- Precision balanced for smooth running with replaceable crankpin bushing that protects the crankshaft from damage
- Rugged one-piece connecting rod
- Solid-end precision type. No bolts or nuts which can come loose
- Factory-filled syntetic lubricants, reduces carbon buildup, extends lubricant change period. Improves compressor performance and life span
