Model: IRUP5TAS380
Performance data and dimensions:
|
Power Model CCN HP |
Capacity
m3/min ft3/min |
Operating
bar(g) |
Pressure
psi(g) |
Voltage V |
Dryer Voltage |
|||
|
Basic Model: Direct-On-Line Starter |
|
|
|
|
|
|||
|
UP5-4TAS-8 |
99313199 |
5 |
0.55 |
19.5 |
8 |
115 |
380 / 415 |
230v/1ph/50hz |
|
UP5-4TAS-10 |
99313207 |
5 |
0.45 |
16 |
10 |
145 |
380 / 415 |
230v/1ph/50hz |
|
UP5-5TAS-8 |
99313223 |
7.5 |
0.82 |
29 |
8 |
115 |
380 / 415 |
230v/1ph/50hz |
|
UP5-5TAS-10 |
99313249 |
7.5 |
0.74 |
26 |
10 |
145 |
380 / 415 |
230v/1ph/50hz |
|
UP5-5TAS-14 |
99313256 |
7.5 |
0.51 |
18 |
14.5 |
210 |
380 / 415 |
230v/1ph/50hz |
|
UP5-7TAS-8 |
99313264 |
10 |
1.08 |
38 |
8 |
115 |
380 / 415 |
230v/1ph/50hz |
|
UP5-7TAS-10 |
99313272 |
10 |
0.96 |
34 |
10 |
145 |
380 / 415 |
230v/1ph/50hz |
|
UP5-7TAS-14 |
99313280 |
10 |
0.64 |
24 |
14.5 |
210 |
380 / 415 |
230v/1ph/50hz |
|
Basic Model: Star-Delta Starter |
||||||||
|
UP5-7TAS-8 |
99313322 |
10 |
1.08 |
38 |
8 |
115 |
380 / 415 |
230v/1ph/50hz |
|
UP5-7TAS-10 |
99313330 |
10 |
0.96 |
34 |
10 |
145 |
380 / 415 |
230v/1ph/50hz |
|
UP5-7TAS-14 |
99313348 |
10 |
0.64 |
24 |
14.5 |
210 |
380 / 415 |
230v/1ph/50hz |
|
UP5-11CTAS-8 |
99313298 |
15 |
1.6 |
56.5 |
8 |
115 |
380 / 415 |
230v/1ph/50hz |
|
UP5-11CTAS-10 |
99313306 |
15 |
1.42 |
50 |
10 |
145 |
380 / 415 |
230v/1ph/50hz |
|
UP5-11CTAS-14 |
99313314 |
15 |
1.08 |
38 |
14.5 |
210 |
380 / 415 |
230v/1ph/50hz |
|
Direct-On-Line Starter on 272L ASME Mounted |
||||||||
|
UP5-4TAS-8-272 |
99334724 |
5 |
0.55 |
19.5 |
8 |
115 |
380 / 415 |
230v/1ph/50hz |
|
UP5-4TAS-10-272 |
99334732 |
5 |
0.45 |
16 |
10 |
145 |
380 / 415 |
230v/1ph/50hz |
|
UP5-5TAS-8-272 |
99334740 |
7.5 |
0.82 |
29 |
8 |
115 |
380 / 415 |
230v/1ph/50hz |
|
UP5-5TAS-10-272 |
99334757 |
7.5 |
0.74 |
26 |
10 |
145 |
380 / 415 |
230v/1ph/50hz |
|
UP5-7TAS-8-272 |
99334765 |
10 |
1.08 |
38 |
8 |
115 |
380 / 415 |
230v/1ph/50hz |
|
UP5-7TAS-10-272 |
99334773 |
10 |
0.96 |
34 |
10 |
145 |
380 / 415 |
230v/1ph/50hz |
|
Direct-On-Line Starter on 272L GB Mounted |
||||||||
|
UP5-5TAS-14-272 |
99317992 7.5 |
0.51 |
18 |
14.5 |
210 |
380 / 415 |
230v/1ph/50hz |
|
|
UP5-7TAS-14-272 |
99318024 10 |
0.64 |
24 |
14.5 |
210 |
380 / 415 |
230v/1ph/50hz |
|
Dimensions (mm) and weight (kg):
- Without air tank: 1042L×734W×914H 330kg
- With 272L air tank: :1311L×734W×1541H 455kg
- With 500L air tank: 2059L×734W×1541H 490kg
